ThinkPad E560 - 2060 LCD Cables

Removalstepsofthecameraandmicrophonemodules
1
2
3
4
4
5
Wheninstalling:Ensurethattheconnectorisattachedfirmly.
2060LCDcables
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage72
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
•“1130Systemboardandthermalfan”onpage86
•“1140dc-in/USB-connectorboardwithcable”onpage91
•“1150Audioconnectorcardwithcable”onpage92
•“1170LCDunit”onpage94
•“2010LCDbezel”onpage100
•“2020LCDpanel”onpage100
Chapter9.RemovingorreplacingaFRU105
