Applyinglabelstothebasecoverassembly
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.Applythoselabelswhen
youreplacethebasecover.Forthelabelsthatarenotshippedwiththenewbasecover,peelthemfromthe
oldbasecover,andadherethemtothenewone.
ThefollowingillustrationshowsthelocationofeachlabelforWindows7andWindows10basedcomputer
models.
1 632 4 5
7
11
10
121314
18
17
16
15
9
8
19
20
IftheWindowsCertificateofAuthentication(COA)label6isattachedtoapartthatisreplaced,returnthe
oldpartwiththelabelattachedtothecustomer,orprovidealettertothecustomerstatingwhatthelabel
wasoriginallyonthecomputerandwhatthelabelpartnumber,serialnumber,andproductkeywere.
Whenyoureplacethebasecover,applytheFCClabel3andtheSerialnumberlabel4.
Forthelabelslistedinthefollowingtable,peelthemofffromtheoldbasecover,andadherethemtothe
newbasecover.
1GEOlabel
2Ratinglabel
5JapanGEOInformationlabel7GMLlabel
8ChinaGEOlabel9KCCsafetylabel
10Chinaproductlabel11IndiaBISlabel
12IndonesiaRatinglabel13Israelhomologationlabel
14ICASAlabel15ChinaWWAN/modemlabel
16IndonesiaPostellabel
17MalaysiaSIRIMlabel
18BrazilAnatellabel
19SVTlabel
20Assettag
IftheremovedcoverhastwoFCClabels,applybothtothenewbasecover.
Chapter9.RemovingorreplacingaFRU99
