ThinkPad E560 - 1150 Audio Connector Card with Cable

1
2
Wheninstalling:Ensurethattheconnectorisattachedfirmlytothesystemboard.
5
6
4
3
StepScrew(quantity)Color
Torque
5
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
1150Audioconnectorcardwithcable
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
92HardwareMaintenanceManual
