ThinkPad E560 - 2070 Wireless LAN Assembly and LCD Rear Cover

2010LCDbezel
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage72
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
•“1130Systemboardandthermalfan”onpage86
•“1140dc-in/USB-connectorboardwithcable”onpage91
•“1150Audioconnectorcardwithcable”onpage92
•“1170LCDunit”onpage94
RemovalstepsoftheLCDbezel
Wheninstalling:Ensurethatallthelatchesareattachedfirmly.
2020LCDpanel
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage72
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
100HardwareMaintenanceManual
