RemovalstepsoftheLCDpanel
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated,smallhead(4)
Black0.181Nm
(1.85kgf-cm)
2
3
5
4
Wheninstalling:EnsurethattheLCDconnectorisattachedfirmly.
