ThinkPad E560 - 2030 LCD Hinges

2030LCDhinges
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage72
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1040Smallbottomcover”onpage74
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1080WirelessLANcard”onpage79
•“1090Coin-cellbattery”onpage81
•“1110Keyboard”onpage81
•“1120Keyboardbezelassembly”onpage83
•“1130Systemboardandthermalfan”onpage86
•“1140dc-in/USB-connectorboardwithcable”onpage91
•“1150Audioconnectorcardwithcable”onpage92
•“1170LCDunit”onpage94
•“2010LCDbezel”onpage100
RemovalstepsoftheLCDhinges
2
2
1
1
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2.5×4mm,wafer-head,nylon-coated(6)Silver
0.294Nm
(3kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
102HardwareMaintenanceManual
