ThinkPad E560 - 1120 Keyboard Bezel Assembly; For Access, Remove These Frus in Order: 1020 Battery Pack; 1030 Large Bottom Cover

5
6
7
8
Wheninstalling:Ensurethattheconnectorisattachedfirmly.
1120Keyboardbezelassembly
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage72
•“1030Largebottomcover”onpage73
•“1050Opticaldriveoroptical-drivebaybezel”onpage75
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage77
•“1110Keyboard”onpage81
Removalstepsofthekeyboardbezelassembly
Note:Dependingonthemodel,yourcomputermightlookdifferentfromtheillustrationsinthistopic.
Chapter9.RemovingorreplacingaFRU83
