15f
15g
15e
15c
15b
15a
15d
16
Wheninstalling:
•Ensurethattheconnectorisattachedfirmly.
•Donotpressthetopofthefancoverandthefanhub.
•Beforeyouattachthefanassemblytothecomputer,applythermalgrease,atanamountof0.2grams,
onthepartmarked
aasshowninthefollowingillustrations.Eithertoomuchortoolessapplicationof
greasecancauseathermalproblemduetoimperfectcontactwithacomponent.Youneedtopeelthe
thinfilmofffromtherubbersmarkedb.
Formodelswithdiscretethermalpipes
a
b
