Table 22. Removal steps of base cover and PC Card/ExpressCard (or ExpressCard/Smart
Card) bezel assembly (continued)
Remove the security hole bracket as in this figure.
1
2
Step Screw (quantity) Color Torque
1 M2 × 3 mm, flat-head, nylon-coated (1) Silver 0.167 Nm(1.7
kgfcm)
Removing and replacing a FRU 115
