1. Assemble the piano near a wall power outlet.
2. Proceed according to the illustrations and exclusively use the supplied screws.
Using other screws could damage the housing of the digital piano or result in a
reduced stability of the digital piano.
n (6) Handscrews (4 pcs.),
n (7) Screws 6 ´ 30 (4 pcs.)
n (8) Screws 4 ´ 15 (5 pcs.) and
n (10) Screws 6 ´ 12 (2 pcs.) for rear wall mounting.
3. Set the pedal box (5) between the left and right side panel ((2) and (3)) and use
2 screws M 6 ´ 30 (7) on each side to affix both side panels to the pedal box.
Insert the four plastic caps (13) into the screw holes.
4.
Attach the rear wall with 5 screws 4 ´ 15 (8) to the pedal box (5) and with two
screws 6 ´ 12 (11) to the rear sides of the side panels ((2) and (3).
5. Put the housing of the digital piano on the stand and affix it using the four
hand screws (6).
Mechanical setup
Setup guide
digital piano
10
