Function Transmitted Received Remarks
Program change True # Yes
***********
Yes
0 – 127
System exclusive No Yes
System common Song position pointer No No
Song select No No
Tune request No No
System real time Clock No No
Commands No No
Aux messages Local ON/OFF No No
ALL notes OFF Yes Yes
Active sensing No Yes
System reset No Yes
Notes: *1
When the accompaniment starts, an FAH message is transmitted.
When the accompaniment stops, an FCH message is transmitted.
When an FAH message is received, the accompaniment starts.
When an FCH message is received, the accompaniment stops.
POLY MONO ON
OMNI ON Mode 1 Mode 2
OMNI OFF Mode 3 Mode 4
MIDI channel mode
MIDI implementation chart
DP-30
47
