Chapter 5
Expert Configuration
E-DOC-CTC-20050429-0104 v1.0
127
5.3.3 Classification
Overview The Classification page consists of three section:
Labels, providing a list of existing packet classification labels and abilities to
add/modify or delete packet classification label entries.
Routing Rules allow you to associate a routing label (used in IP Routing) to a
data flow by means of classification rules.
IPQoS Rules allow you to associate an IP QoS label (used in IP QoS) to a data
flow by means of classification rules.
Labels The Labels section provides an overview of existing packet-classification labels.
The Labels table provides following information per label:
the packet-classification label Name
the kind of packet Classification
the Class of of classification
the TCP Ack class
whether TOS Marking is enabled or disabled.
Proceed as follows to create a new label:
1 Click New to add a label.
2 Fill in all the fields.
3 Click Apply.
