YOUR RECEIVER
2.0 YOUR RECEIVER
2.1 PIN code default: 0000
2.2 Front panel
Fig. 1
1. Standby/on button: To turn the unit ON or to standby mode.
2. Channel up/down To change channels without using the remote
control
3. Volume up/down To change volume without using the remote control
4. Remote control sensor: Receives the signal from the remote control
5. Standby indicator: Shows power state of the receiver
Green LED - receiver is turned on
Red LED - receiver is in standby mode
6. LED display: Shows channel number in operation and time in
Standby
7. USB For connection of external storage devices
2.3 Rear panel
Fig. 2
1. SAT IN To connect to the LNB of your satellite dish for
reception of satellite broadcast signal
2. SAT OUT To loop through the satellite signal to a second
receiver
3. S/PDIF To connect to a digital or home cinema audio
amplifier
4. HDMI To connect to the HDMI input of your TV using a
good quality HDMI cable.
5. TV SCART To connect to TV using a SCART cable
6. DVD/VCR SCART To connect to a Video or DVD recorder
7. Power cord The receiver requires a mains voltage of 100~240V
AC 50~60Hz (auto selecting). Please check the
local power conditions before connecting the
receiver to the mains supply.
2.4 Remote Control
Fig. 3
1. q Turns the receiver ON/standby
2. ! To turn the sound on or off
3. RED Alphabetic search of channels in channel list
mode; several functions in the OSD menu
and Teletext
4. GREEN In viewing mode: changes the resolution of the
HDMI output between 1080p, 1080i, 720p, 576p
and 576i; several functions in the OSD menu
and Teletext.
