© 2013 Thorlabs GmbH144
DCx Cameras
4.2.4 Setting Camera Parameters
Setting and getting parameters : Using these functions, you can make settings for the camera and for image
capture and preprocessing.
The DCxCamera's automatic image control features allow automatically adjusting image brightness and
image color to changing ambient conditions.
Image preprocessing : These functions specify e.g. how color images are processed after image capture.
Querying the camera status : With these functions, you can query additional useful information on the camera
status.
Using the camera EEPROM : All DCx Cameras have a non-volatile EEPROM where you can save the camera
settings or any other information.
4.2.4.1 Setting and Getting Parameters
Capture parameters
This set of functions specifies the camera's image capture parameters, such as exposure, pixel clock and frame
rate:
is_ColorTemperature()
Sets the color temperature
is_Exposure()
Returns the adjustable exposure range.
is_GetFramesPerSecond()
Returns the current frame rate in live mode.
is_GetFrameTimeRange()
Returns the adjustable frame rate range.
is_PixelClock()
Returns the adjustable pixel clock range.
is_SetAutoParameter()
Enables/disables automatic imaging functions.
is_Blacklevel()
Turns black level correction on / off.
is_Exposure()
Sets the exposure time.
is_SetFrameRate()
Sets the frame rate.
is_SetGainBoost()
Sets additional sensor hardware gain boost.
is_SetGamma()
Sets the gamma value (digital post-processing).
is_SetHardwareGain()
Enables the sensor hardware gain.
is_SetHWGainFactor()
Sets the sensor hardware gain factor.
is_PixelClock()
Sets the pixel clock frequency.
is_ResetToDefault()
Resets the camera parameters to its default values.
Image geometry
This set of functions lets you influence the image geometry for image capture, e.g. the area of interest:
is_ImageFormat()
Sets a predefined image size
is_AOI()
Sets the size and position of an area of interest (AOI)
or of a reference AOI for auto imaging functions.
is_SetBinning()
Sets the binning modes.
is_SetRopEffect()
Makes real-time geometry changes to an image (Rop =
raster operation)
is_SetSensorScaler()
Scales the image in the camera
is_SetSubSampling()
Sets the subsampling modes.
Processing image data
The following set of functions refers to the further processing of image data in the PC:
is_GetColorDepth()
Determines the desktop color mode set in the graphics
card.
is_GetTimeout()
Returns the user-defined timeout values.
144
147
148
148
148
180
216
240
241
294
303
170
216
329
331
332
333
335
294
299
267
159
310
340
343
347
237
256
