DCx Cameras
6.3 Color and Memory Formats
Attention
Obsolete parameters
The following parameters for color formats are obsolete and should no longer be used (see also
is_SetColorMode() ):
IS_SET_CM_RGB32
IS_SET_CM_RGB24
IS_SET_CM_RGB16
IS_SET_CM_RGB15
IS_CM_UYVY_MONO_PACKED
IS_CM_UYVY_BAYER_PACKED
IS_CM_BAYER_RG8 (identical to IS_CM_SENSOR_RAW8)
IS_CM_BAYER_RG12 (identical to IS_CM_SENSOR_RAW12)
IS_CM_BAYER_RG16 (identical to IS_CM_SENSOR_RAW16)
IS_CM_BGR555_PACKED (has been renamed to IS_CM_BGR5_PACKED)
Each color format supported by the DCx camera defines a different memory format. The following table shows the
byte arrangement in memory:
