THORLABS DCU223x User Manual

© 2013 Thorlabs GmbH418
DCx Cameras
4.5.29 is_SetBadPixelCorrectionTable
USB 2.0
USB 2.0
Syntax
INT is_SetBadPixelCorrectionTable (HIDS hCam, INT nMode, WORD* pList)
Description
Attention
This function is obsolete and should not be used anymore. We recommend to use the is_HotPixel()
function instead (see also Obsolete functions ).
is_SetBadPixelCorrectionTable() can be used to set the table containing the hot pixel positions which will
be used by the user-defined hot pixel correction function. You can enable hot pixel correction by calling
is_SetBadPixelCorrection() . Each value in the table consists of a 2-byte WORD data type. The first value
indicates the number of pixel coordinates in the table, the coordinates are listed subsequently (first X, then Y).
A table with 3 hot pixels must be structured as follows:
3
X1
Y1
X2
Y2
X3
Y3
Input parameters
hCam
Camera handle
nMode
IS_SET_BADPIXEL_LIST
Sets a new user-defined list.
The pList parameter points to a list which has the
format described above.
IS_GET_LIST_SIZE
Returns the number of pixel coordinates included in the
user-defined list.
If the list contains no coordinates, the return value is -1.
IS_GET_BADPIXEL_LIST
Copies the user-defined list to the pList parameter.
Make sure to allocate the memory accordingly.
pList
Pointer to the starting address of the hot pixel table
Return values
IS_SUCCESS
Function executed successfully
IS_NO_SUCCESS
General error message
When used with
IS_GET_LIST_SIZE
Number of coordinates in the list
If the list contains no coordinates, the return value is -1.
Related functions
is_LoadBadPixelCorrectionTable()
is_SaveBadPixelCorrectionTable()
is_SetBadPixelCorrection()
