THORLABS DCU223x User Manual

© 2013 Thorlabs GmbH
4 Programming (SDK)
319
4.3.79 is_SetColorMode
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_SetColorMode (HIDS hCam, INT Mode)
Description
is_SetColorMode() sets the color mode to be used when image data are saved or displayed by the graphics
card. For this purpose, the allocated image memory must be large enough to accommodate the data with the
selected color mode. When images are transferred directly to the graphics card memory, make sure that the
display settings match the color mode settings. Otherwise, the images will be displayed with altered colors or are
not clearly visible.
Notes
Display Modes
This function is only supported in the bitmap (DIB) display mode. Use the is_SetDisplayMode() function to
display other color formats in Direct3D or OpenGL mode.
Bit Depth
Color formats with a bit depth of more than 8 bits per channel are not supported by DCx camera models.
RGB15/16
For the RGB16 and RGB15 data formats, the MSBs of the internal 8-bit R, G and B colors are used.
Input parameters
hCam
Camera handle
Mode: Color mode to be set. For a list of all available color formats and the associated input parameters, see the
Appendix: Color and memory formats section.
IS_CM_MONO16
Grayscale (16), for monochrome and color cameras, LUT/gamma active
IS_CM_MONO12
Grayscale (12), for monochrome and color cameras, LUT/gamma active
IS_CM_MONO8
Grayscale (8), for monochrome and color cameras, LUT/gamma active
IS_CM_SENSOR_RAW16
Raw sensor data (16), for monochrome and color cameras, LUT/gamma
active
IS_CM_SENSOR_RAW12
Raw sensor data (12), for monochrome and color cameras, LUT/gamma
active
IS_CM_SENSOR_RAW8
Raw sensor data (8), for monochrome and color cameras, LUT/gamma active
IS_CM_RGB12_PACKED
RGB36 (12 12 12), for monochrome and color cameras, LUT/gamma active.
IS_CM_RGB10_PACKED
RGB30 (10 10 10), for monochrome and color cameras, LUT/gamma active
IS_CM_RGB8_PACKED
RGB24 (8 8 8), for monochrome and color cameras, LUT/gamma active
IS_CM_RGBA12_PACKED
RGB48 (12 12 12), for monochrome and color cameras, LUT/gamma active
IS_CM_RGBA8_PACKED
RGB32 (8 8 8), for monochrome and color cameras, LUT/gamma active
IS_CM_RGBY8_PACKED
RGBY (8 8 8 8), for monochrome and color cameras, LUT/gamma active
IS_CM_BGR12_PACKED
BGR36 (12 12 12), for monochrome and color cameras, LUT/gamma active
IS_CM_BGR10_PACKED
BGR30 (10 10 10), for monochrome and color cameras, LUT/gamma active
IS_CM_BGR8_PACKED
BGR24 (8 8 8), for monochrome and color cameras, LUT/gamma active
IS_CM_BGRA12_PACKED
BGR48 (12 12 12), for monochrome and color cameras, LUT/gamma active
IS_CM_BGRA8_PACKED
BGR32 (8 8 8), for monochrome and color cameras, LUT/gamma active
IS_CM_BGRY8_PACKED
BGRY (8 8 8), for monochrome and color cameras, LUT/gamma active
