THORLABS DCU223x User Manual

© 2013 Thorlabs GmbH
5 Specifications
461
5.3.1 DCC1240x / DCC3240x
Sensor specification
Sensor type
CMOS
Shutter system
Electronic global and rolling shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.3 Megapixel)
Aspect ratio
5:4
Bit depth
10 bits *
8
Optical sensor class
1/1.8 inch
Exact sensitive area
6.784 mm x 5.427 mm
Exact optical sensor diagonal
8.69 mm (1/1.84 inch)
Pixel size
5.30 µm, square
Micro lens shift
12°
Sensor name, monochrome
e2v EV76C560ABT
Sensor name, color
e2v EV76C560ACT
Sensor name, NIR
*7
e2v EV76C661ABT
Special features
Automatic hotpixel correction in the sensor, see is_HotPixel()
Multi AOI with 2 or 4 AOI, see Camera basics: AOI
Sequence AOI
Sensor internal image scaler, downscaling by factor 1...4, see
is_SetSensorScaler() and uc480 Viewer: Size )
Allows to switch between global and rolling shutter readout, see
is_DeviceFeature()
Gain
Monochrome model (master gain)
4x
Color model (master / RGB)
4x / 3.96x
Gain boost
2x
Camera timing
DCC1240x
DCC3240x
Pixel clock range (allowed/
recommended)
MHz
7 to 35 / 35
*1
5 to 85 / 85
*1
Max. pixel clock with subsampling/
binning
MHz
85
*1
85
*1
Frame rate (freerun mode)
fps
25.8
*2
60.0
*2
Frame rate (trigger mode, 1 ms
exposure)
fps
24.7
*2
56.9
*2
Exposure time in freerun mode
ms
0.009
*2
to 2000
*3
0.009
*2
to 2000
*3
Exposure time in trigger mode
ms
0.009
*2
to 2000
*3
0.009
*2
to 2000
*3
AOI
Mode
Horizontal + Vertical
*4
AOI image width, step width
Pixels
16 to 1280, 4
16 to 1280, 4
AOI image height, step width
Pixels
4 to 1024, 2
4 to 1024, 2
AOI position grid horizontal, vertical
Pixels
2, 2
2, 2
AOI frame rate, 640 x 480 pixels
(VGA)
fps
52.0
123.0
AOI frame rate, 320 x 240 pixels
(CIF)
fps
98.0
229.0
41
25
260
35
343 97
192
