THORLABS DCU223x User Manual

© 2013 Thorlabs GmbH464
DCx Cameras
5.3.2 DCC1545M
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.31 Megapixel)
Aspect ratio
5:4
Bit depth
10 bits
Optical sensor class
1/2 inch
Exact sensitive area
6.656 x 5.325 mm
Exact optical sensor diagonal
8.52 mm (1/1.88 inch)
Pixel size
5.20 µm, square
Sensor name
Aptina MT9M001 (monochrome)
Gain
Monochrome model (master gain)
13x
Analog gain boost
1.5x
Camera timing
Pixel clock range
MHz
5 to 43
*1
Max. pixel clock with subsampling/
binning
MHz
48
*1
Frame rate (freerun mode)
fps
25.0
*2
Frame rate (trigger mode, 1 ms
exposure)
fps
25.0
*2
Exposure time in freerun mode
ms
0.037
*2
to 983
*2
Exposure time in trigger mode
ms
0.037
*2
to 983
*2
AOI
Mode
Horizontal
*4
+ Vertical
*4
AOI image width, step width
Pixels
32 to 1280, 4
AOI image height, step width
Pixels
4 to 1024, 2
AOI position grid horizontal, vertical
Pixels
4, 2
AOI frame rate, 640 x 480 pixels (VGA)
fps
84
Binning
Mode
none
Subsampling
Mode
Horizontal
*4
+ Vertical
*4
Method
H + V: Color subsampling
Factor
2x, 4x, 8x
Frame rate w/ 2x subsampling, 640 x
480 pixels
fps
94
Frame rate w/ 4x subsampling, 320 x
240 pixels
fps
258
Hardware trigger
Mode
Asynchronous
Trigger delay with rising edge
µs
22.0 ±0.25
Trigger delay with falling edge
µs
40.3 ±0.25
41
