30 HA0365T Rev D Jan 2017
Chapter 4
4.4.7 Menu Option - Joystick mode
This mode is used to set the operating mode of the
joystick wheel.
Press the MENU bu tton, then use the wheel to scroll
through the menu options
Press the MENU button to enter the 5 Joystick mode
option. Use the wheel to scroll through the options.
The display shows the current setting.
In Jog voltage mode, deflecting the wh eel initiates a
change in the dri ve voltage, using the pa rameters
specified by the Step parameter in the 6 Joystick menu
option - see Section 4.4.8. The voltage is increa sed or
decreased by one step per click of the wheel.
In Voltage adjust mode, the wheel can be used to
increase and decrease the drive voltage. The voltage
change is prop ortional to th e deflection of the wh eel
according to the setting in the Speed parameter in the
6 Joystick menu option - see Section 4.4.8.
In Go to voltage mode, deflecting the wheel changes the
voltage from the cu rrent value to one of the two
predefined “teach voltage” values. The teach voltages
are specified in option 7 Teach voltage - see Section
4.4.9.
Use the wheel to display the required option, then press
MENU to store the selection and return to the main
display.
The selected mode is indicated at the right hand side of
the bottom line:
A = Voltage adjust mode
J = Jog to voltage mode
G = Go to voltage
Menu options
5 Joystick mode
Menu options
Use wheel
MENU
Jog voltage
to change
Voltage: 0.00V
150V A J
Voltage adjust
to change
Position: 0.00%
150V 1 A
