LDC200C Series
5 Appendix
5.1 Technical Data
Common Technical Data
General Data
Safety Features
Interlock
Laser Current Limit
Soft Start
Short Circuit when Laser off
Open Circuit Detection
Overtemperature Protection
Display
LED, 5 Digits
Connector for Laser, Photodiode, Interlock &
Laser On Signal
9-pin D-Sub Jack
Connectors for Control Input / Output
BNC
Chassis Ground Connector
4mm Banana Jack
Line Voltage
100 V
115 V +15% / –10%
230 V
Mains Supply Overvoltage
Category II (Cat II)
Line Frequency
50 to 60 Hz
Operating Temperature Range
1
)
0°C to +40 °C
Storage Temperature Range
-40°C to +70 °C
Relative Humidity
Max. 80% up to 31 °C, decreasing to 50% at 40 °C
Pollution Degree (Indoor Use only)
2
Operation Altitude
<2000 m
Warm-up Time for Rated Accuracy
10 min
Dimensions (W x H x D)
w/o Operating Elements
with Operating Elements
146 x 66 x 290 mm³
146 x 77 x 320 mm³
1
) non-condensing
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
