THORLABS LDC200C series User Manual

© 2015 Thorlabs
5 Appendix
31
5.1.7 LDC240C
Current Control (Constant Current Mode)
Control Range
0 to ±4 A
Compliance Voltage
>5 V
Resolution
100 µA
Accuracy
±4.0 mA
Noise Without Ripple (10Hz to 10MHz, rms, typ.)
<50 µA
Ripple (50/60Hz, rms, typ.)
<8 µA
Transients (typ.)
<4 mA
Drift, 24hours
(typ., 0-10Hz, at constant ambient temperature)
<200 µA
Temperature Coefficient
<50 ppm/°C
Current Limit
Setting Range
0 to >4 A
Resolution
100 µA
Accuracy
± 10 mA
Power Control (Constant Power Mode)
Photo Current Control Range
50 µA to 20 mA
Photo Current Resolution
1 µA
Photo Current Accuracy
±20 µA
Analog Modulation Input
Input Resistance
10 kW
Small Signal 3dB Bandwidth, CC Mode
DC to 30 kHz
Modulation Coefficient, CC Mode
400 mA/V ±5%
Modulation Coefficient, CP Mode
2 mA/V ±5%
Laser Current Monitor Output
Load Resistance
>10 kW
Transmission Coefficient
2.5 V/A ±5%
General data
Maximum Power Consumption
100 VA
Weight
<3.3 kg
All technical data are valid at 23 ± 5°C and 45 ±15% humidity
