LDC200C Series
5.1.2 LDC201CU
Current Control (Constant Current Mode)
Control Range
0 to ±100 mA
Compliance Voltage
>5 V
Resolution
10 µA
Accuracy
±50 µA
Noise Without Ripple (10Hz to 10MHz, rms, typ.)
<0.2 µA
Ripple (50/60Hz, rms, typ.)
<0.5 µA
Transients (typ.)
<10 µA
Drift, 24hours
(typ., 0-10Hz, at constant ambient temperature)
<2 µA
Temperature Coefficient
<50 ppm/°C
Current Limit
Setting Range
0 to >100 mA
Resolution
10 µA
Accuracy
± 200 µA
Power Control (Constant Power Mode)
Photo Current Control Range
25 µA to 10 mA
Photo Current Resolution
1 µA
Photo Current Accuracy
±10 µA
Analog Modulation Input
Input Resistance
10 kW
Small Signal 3dB Bandwidth, CC Mode
DC to 0.2 kHz
Modulation Coefficient, CC Mode
10 mA/V ±5%
Modulation Coefficient, CP Mode
1 mA/V ±5%
Laser Current Monitor Output
Load Resistance
>10 kW
Transmission Coefficient
100 V/A ±5%
General data
Maximum Power Consumption
20 VA
Weight
<3.1 kg
All technical data are valid at 23 ± 5°C and 45 ±15% humidity
