LDC200C Series
5.1.4 LDC205C
Current Control (Constant Current Mode)
Control Range
0 to ±500 mA
Compliance Voltage
>10 V
Resolution
10 µA
Accuracy
±0.5 mA
Noise Without Ripple (10Hz to 10MHz, rms, typ.)
< 3 µA
Ripple (50/60Hz, rms, typ.)
< 2 µA
Transients (typ.)
< 0.5 mA
Drift, 24hours
(typ., 0-10Hz, at constant ambient temperature)
<10 µA
Temperature Coefficient
<50 ppm/°C
Current Limit
Setting Range
0 to >500 mA
Resolution
10 µA
Accuracy
±1.5 mA
Power Control (Constant Power Mode)
Photo Current Control Range
25 µA to 10 mA
Photo Current Resolution
1 µA
Photo Current Accuracy
±10 µA
Analog Modulation Input
Input Resistance
10 kW
Small Signal 3dB Bandwidth, CC Mode
DC to 150 kHz
Modulation Coefficient, CC Mode
50 mA/V ±5%
Modulation Coefficient, CP Mode
1 mA/V ±5%
Laser Current Monitor Output
Load Resistance
>10 kW
Transmission Coefficient
20 V/A ±5%
General data
Maximum Power Consumption
30 VA
Weight
<3.1 kg
All technical data are valid at 23 ± 5°C and 45 ±15% humidity
