THORLABS LDC200C series User Manual

© 2015 Thorlabs
5 Appendix
29
5.1.5 LDC210C
Current Control (Constant Current Mode)
Control Range
0 to ±1 A
Compliance Voltage
>10 V
Resolution
100 µA
Accuracy
±1.0 mA
Noise Without Ripple (10Hz to 10MHz, rms, typ.)
<5 µA
Ripple (50/60Hz, rms, typ.)
<3 µA
Transients (typ.)
<1 mA
Drift, 24hours
(typ., 0-10Hz, at constant ambient temperature)
<20 µA
Temperature Coefficient
<50 ppm/°C
Current Limit
Setting Range
0 to >1 A
Resolution
100 µA
Accuracy
± 2.5 mA
Power Control (Constant Power Mode)
Photo Current Control Range
50 µA to 20 mA
Photo Current Resolution
1 µA
Photo Current Accuracy
±20 µA
Analog Modulation Input
Input Resistance
10 kW
Small Signal 3dB Bandwidth, CC Mode
DC to 100 kHz
Modulation Coefficient, CC Mode
100 mA/V ±5%
Modulation Coefficient, CP Mode
2 mA/V ±5%
Laser Current Monitor Output
Load Resistance
>10 kW
Transmission Coefficient
10 V/A ±5%
General data
Maximum Power Consumption
40 VA
Weight
<3.1 kg
All technical data are valid at 23 ± 5°C and 45 ±15% humidity
