3.8 Subpanels
In the Numerical screen, 6 subpanels can be configured in order to display additional results:
To configure a subpanel, tap to it and select from the drop-down list the desired parameter.
Please note, that additional parameters are sensor-dependent, as stated in the table below:
Photodiode Sensors
Thermal Sensors
Pyro-Electric Sensors
----- (none)
----- (none)
----- (none)
Current
Voltage
Voltage
Power F
e
Power F
e
Energy W
DET
Power F
e
dBm
Power F
e
dBm
(not available)
Max
Max
Max
Min
Min
Min
Ratio (Max/Min)
Ratio (Max/Min)
Ratio (Max/Min)
Sensor Temperature
1
)
Sensor Temperature
1
)
(not available)
Frequency
Frequency
Frequency
Ext. NTC Temperature
Ext. NTC Temperature
Ext. NTC Temperature
Irradiance E
e
Irradiance E
e
Fluence H
e
1
) - Available only if a sensor-internal temperature sensor is detected.
