THORLABS PM400 - Technical Data

© 2017 Thorlabs GmbH56
PM400
7.2 Technical Data
Features
Detector Compatibility
Photodiode Sensors S100C Series
Thermal Sensors S300C Series
Pyroelectric Sensors ES100C/ES200C Series
Photodiodes (Max 5 mA)
Thermopiles (Max 1 V)
Pyroelectric detectors (Max 100 V)
Display Type
4.3" TFT, WQVGA, 400 x 272 Pixels, 16 bit Color
Viewing Area
95 mm x 54 mm
Display Update Rate (max)
10 Hz Numerical, 25 Hz Analog Simulation
Display Format
Numerical, Bargraph, Trendgraph, Statistics, Simulated Analog
Needle
Backlight Display
LED, Adjustable
Features
Capacitive Touchscreen and Buttons, Support Stand, Rubberized
Outside,
2 x M3 Thread Inserts for Mounting on Back Side
Current Input (Photodiode Sensors)
Connector
DB9F
Units
W, dBm, W/cm², A
Measurement Ranges
6 Decades; 50 nA - 5 mA
Ranges Selectable in W, Sensor Dependent
Display Resolution
1 pA / Responsivity Value (A/W)
AD Converter
16 bit
Accuracy
±0.2% f.s. (5 µA - 5 mA)
±0.5% f.s. (50 nA)
Bandwidth
DC - 100 kHz, Dependent on Sensor and Settings
Wavelength Correction
nm (A/W)
Beam Area Setting
Diameter 1/e² or Rectangular x,y
Voltage Input (Thermopile Sensors)
Connector
DB9F
Units
W, dBm, W/cm², V
Measurement Ranges
9 Ranges: 2, 4, 10, 20, 40, 100, 200, 400, 1000 mV
Ranges Selectable in W, Sensor Dependent
Display Resolution
1 µV / Responsivity Value (V/W)
AD Converter
16 bit
Accuracy
±0.5% f.s. (10 mV - 1 V)
±1% f.s. (2mV)
Bandwidth
DC - 10 Hz, Dependent on Sensor and Settings
Time Constant Correction Range
1 s - 30 s
Wavelength Correction
Sensor Dependent; nm, (V/W)
Beam Area Setting
Diameter 1/e² or Rectangular x,y
