2GX/AERO X Owner’s Manual
ix
CORBAC
®
ADJUSTABLE CONTOUR BACK SUPPORT 7-3
TENSION ADJUSTABLE SLIDE-IN SEAT SLING 7-3
Adjusting the Tension 7-4
Replacing 7-4
SLIDE-IN SEAT TUBE EXTENSION (Adjustable Depth) 7-5
Installing 7-5
ADJUSTABLE SEAT DEPTH 7-5
Adjusting 7-5
SEAT CUSHIONS 7-6
Replacing the Foam Insert in the TiLite Seat Cushion 7-6
VELCRO
®
-STYLE ADJUSTABLE SEAT BELT 7-7
Installation 7-7
Adjustment 7-7
Safety Check 7-7
Maintenance 7-8
QUICK-RELEASE SOLID SEAT PAN (Aluminum) 7-8
CHAPTER 8: AXLE PLATES & CAMBER PLUGS
(CENTER OF GRAVITY; REAR SEAT HEIGHT) 8-1
STANDARD CAMBER PLUG 8-1
Adjusting the Center of Gravity 8-1
Adjusting the Rear Seat Height 8-2
Adjusting the Rear Wheel Spacing/Replacing the Camber Plugs 8-3
ADJUSTING TOE-IN/TOE-OUT 8-5
CHAPTER 9: AXLES AND AMPUTEE ADAPTERS 9-1
STAINLESS AND TITANIUM QUICK-RELEASE AXLES 9-1
Adjusting the Quick-Release Axle 9-1
QUAD QUICK-RELEASE AXLES 9-1
Adjusting the Quad Quick-Release Handle 9-1
Adjusting the “Play” 9-3
AMPUTEE ADAPTERS 9-4
CHAPTER 10: WHEEL LOCKS 10-1
COMPACT PUSH TO LOCK 10-1
Adjusting 10-1
Replacing
10-1
COMPACT PULL TO LOCK 10-2
Adjusting
10-2
Replacing 10-2
COMPACT PUSH TO LOCK AND COMPACT PULL TO LOCK WITH EXTENSION HANDLE
. 10-2
UNI-LOCK 10-2
Adjusting 10-2
Replacing 10-3
Changing the Uni-Lock from the Push to the Pull Position 10-3
Repositioning the Handle of the Uni-Lock Wheel Lock 10-4
UNI-LOCK WITH EXTENSION HANDLES 10-5
COMPACT SCISSOR LOCK 10-5
Adjusting
10-5
Replacing 10-6
