2 Installation
Install the digital TV receiver, limited by the specifications shown in the table
below.
Input voltage AC 100–250 V, 50/60 Hz
Maximum power consumption 55 W when in operation
1 W when in standby mode
Size 340 mm × 60 mm × 2450 mm
Weight 2 kg with no hard drive
Operating temperature 32–113 °F, 0–45 °C
Storage temperature 14–158 °F, -10–70 °C
This digital TV receiver has a variety of connectors:
• Aerial connectors
• AV connectors for a TV and an AV receiver
• USB ports for removable storage devices and the Wi-Fi dongle
• An e-SATA port for a removable hard drive
The RS-232C port may be used only by an engineer for installation or service.
8
