Toa RM-200SF - Specifications; VX-3004 F Voice Evacuation Frame 4 SS

4-4
Chapter 4 APPENDIX
Power Source 31 V DC (operating range: 20 to 33 V DC), removable terminal block (4 pins)
Power Consumption 18 W at 31 V DC
Indicator POWER (green) ...1, RUN (green) ...1, EMERGENCY (red) ...1, CPU OFF (red) ...1,
LAN A (green) ...1, LAN B (green) ...1, RS LINK A (green) ...1, RS LINK B (green) ...1
FAULT STATUS (yellow):
GENERAL ...1, UNIT* ...1, NETWORK* ...1, EMG MIC* ...1, FUSE* ...1,
POWER* ...1, CPU ...1, ZONE ...8
AMPLIFIER: PEAK (red) ...4, SIGNAL (green) ...4, OPERATE (green) ...4,
POWER (green)* ...4
* By default
Operation Fault Control Switch ...2 (ACK/RESET)
Test Switch ...1 (LAMP TEST)
Setting Switch: ID NUMBER, RESET, IMPEDANCE, Setting (internal front panel)
LAN A, B Number of Connectors: 2 (LAN A, LAN B)
Network I/F: 100BASE-TX
Network Protocol: TCP, UDP, ARP, ICMP, RTP, IGMP, FTP, HTTP
Spanning tree Protocol: RSTP
Audio Transmission System: TOA Packet Audio
Audio Encoding Method: PCM
Audio Sampling Frequency: 48 kHz
Audio Quantifying Bit Number: 16 bits
Connection Device: other VX-3004F, VX-3008F, VX-3016F, Switching HUB
Connector: RJ45 connector
Connection Cable: Category 5 twisted pair cable (CAT5)
Number of Stages of Cascade connection:
UP to 7
Maximum Cable Distance: 100 m (328.08 ft)
RS Link A, B Number of Connectors: 2 (RS LINK A, RS LINK B)
Audio input level: 0 dB *
2
Power feed: Max. 1 A per connector
Connector: RJ45 connector
Connection Cable: S hielded Category 5 twisted pair cable (CAT5-STP)
Maximum Cable Distance: 1200 m (3937.01 ft)
DS Link Connection Device: DS LINK of Power supply units
Connector: RJ45 connector
Connection Cable: Shielded Category 5 twisted pair cable (CAT5-STP)
Maximum Cable Distance: 5 m (16.4 ft)
Analog Link Number of Connectors: 1 input, 1 output
Connection Device: other VX-3004F, VX-3008F, VX-3016F
Connector: RJ45 connector
Connection Cable: Shielded Category 5 twisted pair cable (CAT5-STP)
Maximum Cable Distance: 800 m (2624.67 ft)
Control Input 1, 2 16 inputs, no-voltage make contact input, open voltage: 24 V DC,
short-circuit current: 2 mA
Fault Detection System: Short circuit, Open circuit, Method: Voltage detect
Connector: RJ45 connector
Connection Cable: Shielded Category 5 twisted pair cable (CAT5-STP)
Emergency Control IN Input2: Isolatedvoltageinput,−24to+24V
Connector: RJ45 connector
Connection Cable: Category 5 twisted pair cable (CAT5)
2. SPECIFICATIONS
2.1. VX-3004F Voice Evacuation Frame 4SS
