Toa RM-200SF - The Zones Allocation Setting

3-5
Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
2.2. The Zones Allocation Setting
FortheVX-3008FandVX-3016Funits,thepresetrelationshipbetweenbroadcastzonesandpowerampliers
can be changed by the settings of the DIP switch inside the front panel.
VX-3008F: You can perform the zone allocation settings for all-zone emergency broadcast at CPU off state.
Note
For normal broadcasts, use the VX-3000 Setting Software to perform this setting.
VX-3016F: You can perform the zone allocation settings for normal broadcasts, and all-zone emergency
broadcast at CPU off state.
[Power amplifier modules inside the VX-3008F and output zone configuration]
Switch
Figure Powerampliermoduleandoutputzoneconguration
1 2 3
OFF OFF OFF AllocatestheSlot1'samplieroutputtoZones1through8.
ON OFF OFF AllocatestheSlot1'samplieroutputtoZones1through7andtheSlot2's
amplieroutputtoZone8.
OFF ON OFF AllocatestheSlot1'samplieroutputtoZones1through6andtheSlot2's
amplieroutputtoZones7and8.
ON ON OFF AllocatestheSlot1'samplieroutputtoZones1through5andtheSlot2's
amplieroutputtoZones6through8.
OFF OFF ON AllocatestheSlot1'samplieroutputtoZones1through4andtheSlot2's
amplieroutputtoZones5through8.
ON OFF ON AllocatestheSlot1'samplieroutputtoZones1through3andtheSlot2's
amplieroutputtoZones4through8.
OFF ON ON AllocatestheSlot1'samplieroutputtoZones1and2andtheSlot2's
amplieroutputtoZones3through8.
ON ON ON AllocatestheSlot1'samplieroutputtoZone1andtheSlot2'samplier
output to Zones 2 through 8.
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
ON
[Power amplifier modules inside the VX-3016F and output zone configuration]
Switch
Figure Powerampliermoduleandoutputzoneconguration
1
OFF Allows to allocate the Slot 1's amplier output to Zones 1 through 16
(1 channel, 16 speaker selectors)
ON AllowstoallocatetheSlot1'samplieroutputtoZones1through8and
theSlot2'samplieroutputtoZones9through16.(2channels,8speaker
selectors)
1 2 3 4
ON
1 2 3 4
ON
