5
5-21
4st 9.9/15/20 2008
3. Remove flywheel and key.
4. Disconnect alternator and pulser coil.
5. Remove bolts of alternator 1 and coil bracket 2, and
remove alternator and coil bracket.
6. Remove bolts and then pulser coil 3.
To prevent damages to engine and special
tools, tighten flywheel puller set bolts
evenly and keep flywheel puller parallel to
flywheel while working.
1
2
3
Screw puller onto crankshaft end until flywheel is
disengaged from tapered section of crankshaft.
Flywheel puller kit :
P/N. 369-72211-0
