Item Unit
MF EF
EP
Model
Engine over-rev protection
Controls engine speed to approx. 6,400 r/min or lower (high speed ESG)
Warning system
Engine oil pressure reduction
protection
Confirmation of operation of
warning system
*5
Controls engine speed to approx. 2,000 r/min or lower (low speed ESG).
Warning buzzer and lamp are turned on.
Only lamp operates (7 seconds).
11.5 (3x9.25x11.5) (3x235x292)
10 (3x9.25x10) (3x235x254)
9 (3x9.25x9) (3x235x229)
Mark
8 (3x9.25x8)in (3x235x203)mm
7 (3x9.2x6.9) (3x234x174)
6 (3x9.2x6.1) (3x234x155)
Tachometer
No. of poles
12
Remote control cable Feet Cable length : 7 - 30ft
Propeller [Mark]
(No. of blades x
Diameter x Pitch)
[in/mm]
*5 To cancel this warning system, engine should be stopped and then restarted.
Optional parts
Bracket
No. of trim steps
No. of steps
6
Trim angle (transom 12°) Degrees 5 - 25°
Shallow water drive angle (transom 12°)
Degrees 32°
Maximum tilt angle Degrees 70°
Steering angle Degrees 70°
mm (in) 40 - 60 (1.57 - 2.36)
*2 Angle from horizontal line when transom is 12°.
*3 Tilt operating range
*4 Steering right-left operating range
*2
*2
*3
*4
Maximum allowable transom
board thickness
To Next Page
