4st 9.9/15/20 2008
1 Drive Shaft "S" 1 for Transom "S"
Drive Shaft "L" 1 for Transom "L"
Drive Shaft "UL" 1 for Transom "UL"
2 Ball Bearing, 7302A 1
3 Bevel Gear "A" 1
4 Bevel Gear "B" 1
5 Bevel Gear "B" Nut 1
6 Bevel Gear "C" 1
7 Washer, 17-22-1.5 1
8 Shim, 35-41.9-0.1 AR
Shim, 35-41.9-0.15 AR
Shim, 35-41.9-0.3 AR
Shim, 35-41.9-0.5 AR
9 Propeller (6), 3 x 234 x 155 1
Propeller (7), 3 x 234 x 174 1
Propeller (8), 3 x 235 x 203 1 STD: 9.9C "L"
Propeller (9), 3 x 235 x 229 1 STD: 9.9C "S" STD: 15C/20C "L"&"UL"
Propeller (10), 3 x 235 x 254 1 STD: 15C/20C "S"
Propeller (11.5), 3 x 235 x 292 1
Propeller (7), 4 x 254 x 178 1
10 Propeller Thrust Holder 1
11 Washer, 12.5-32-2.5 1
12 Propeller Nut 1
13 Split Pin, 3-22 1
14 Propeller Shaft 1
15 Clutch 1
16 Clutch Pin 1 ø5-30mm
17 Clutch Pin Snap 1
18 Clutch Spring 1
19 Clutch Spring Retainer 1
20 Clutch Push Rod 1
21 Steel Ball, 3/8 1
22 Water Pump Impeller 1
23 Water Pump Impeller Key 1
24 Pump Case (Upper) 1
25 Pump Case Liner 1
26 Pump Case (Lower) 1
27 Oil Seal, 13.8-26-9.5 1
28 O-Ring, 3.5-36 1
29 Water Pump Guide Plate 1
30 Bolt 3
31 Water Pipe Seal (Lower) 1
32 Clutch Cam 1
33 Cam Rod "S" 1 for Transom "S"
Cam Rod "L" 1 for Transom "L"
Cam Rod "UL" 1 for Transom "UL"
34 Spring Pin, 3-12 2
35 Cam Rod Bushing 1
36 O-Ring, 2.4-5.8 2
37 O-Ring, 3.5-36 1
38 Cam Rod Bushing Stopper 1
39 Bolt 1
40 Shift Rod 1
41 Shift Rod Joint 1
42 Spring Pin, 3-12 2
43 Propeller Hard Wear Kit set
Ref.
No.
Description
RemarksQ'ty
Do not reuse.
Selection if necessary.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
E_MFS20C_ch06_081216.qxd 09.1.20 5:27 PM ページ 7
