TOHATSU MFS 20C User Manual

7-13
4st 9.9/15/20 2008
7
5) Disassembly of Drive Shaft Housing
1. Remove upper rubber mount installation bolts 1 and then
remove rubber mount from drive shaft housing.
6. Remove nuts of upper rubber mount 6.
7. Remove drive shaft housing 7 from clamp bracket ass’y.
Be careful not to drop drive shaft housing when
removing the housing from clamp bracket.
2
1
7
6
2. Check rubber mount 2 for abnormality such as crack.
Replace if any abnormality is found.
E_MFS20C_ch07_081216.qxd 09.1.20 5:40 PM ページ 13
