4st 9.9/15/20 2008
Lower Unit
Propeller
shaft housing
Bracket
Tiller
handle
Bottom
cowl













○
○







○


















○
○
○
○
○
○


○

○

○

○
○



○

○
○
○
○
○
○
○


○
○
○
○
Bolt (propeller shaft housing)
O ring
Oil seal
Propeller shaft
Needle bearing
Clamp screw
Swivel bracket (steering shaft bore)
Swivel bracket (bracket bolt)
Swivel bracket (tilt stopper mount)
O ring (steering shaft)
Reverse lock (arm and lever)
Co-pilot bolt
Nut 7/8 (bracket bolt)
Bolt (steering bracket)
Bushing (tiller handle)
Throttle shaft
Throttle wire
Grommet (shift rod)
Grommet (throttle cable)
Grommet (PT cord)
Seal (upper part of cover)
Thread
Lip
Periphery, at press fitting
Spline
at press fitting
Thread
Fill interior with grease.
Sliding face
Sliding face
at assembling
Movable area
Female side
Fixed side nut
when bolt is reused
Inner and outer surfaces
Inner and outer surfaces
Lip
Press fit section
1000ml when replaced,
or 1200ml when disassembled
Oil capacity 370ml
Apply to Remarks
Drive shaft
housing cover
Nipples
Amount of engine oil
Gear case
Screw locking agent Gasket sealing agent Instantaneous adhesive Adhesive Water resistant grease OBM Teflon grease TEF Silicone grease SOC Molybdenum grease MOL 4 stroke engine oil Tohatsu genuine gear oil Cold resistant lithium grease LIT
271 1342 1373
ThreeBond
ThreeBond
LOC-
TITE
LOC-
TITE
Konishi
Shin-Etsu
Chemical
SUMICO
LUBRI-
CANT
1361 518 G17
Centax L2
FM-
531
LM-
902
KS-64 5001207B 1741
Sliding face
(except slide adjusting section)
