3-28
Maintenance
4st 9.9/15/20 2008
WARNING
Screw-in remote control cable joint at lease
10mm
a
.
6. Loosen lock nut 1, remove snap pin and washer, and then
remote control cable joint. (Throttle lever is not shown to
make the working procedure more comprehensible.
1
7. Adjust remote control cable length so that the cable joint 2
hole aligns with set pin.
a
2
1
3
8. Reconnect remote control cable joint 1, attach snap pin 3,
and tighten lock nut.
9. Check if gear shifts smoothly, and repeat steps 2. to 8. as
necessary.
Adjust remote control cable joint with remote
control cable fully pushed in.
