Fuel System
4-4
4st 9.9/15/20 2008
1 Carburetor 1 for MF & EF (3BJFA)
Carburetor 1 for EP (3BAPA)
Carburetor - for MF & EF (3BHFA)
Carburetor - for EP (3AZPA)
Carburetor - for MF & EF (3FSFA)
1-1 Main Jet #121 1
1-2 Plug 1
1-3 Main Jet #99 -
Main Jet #88 -
1-4 Plug -
1-5 O-Ring 1
1-6 Slow Jet #52 1
Slow Jet #46 -
Slow Jet #43 -
1-7 Main Nozzle 1 for MF & EF
Main Nozzle 1 for EP
Main Nozzle - for MF & EF
Main Nozzle - for EP
Main Nozzle - for MF & EF
1-8 Float Valve 1
1-9 Float Arm Pin 1
1-10 Float 1
1-11 Screw 1
Screw -
1-12 Stop Screw 1 L=18
1-13 Spring 1 L=14
1-14 Float Chamber 1
Float Chamber -
1-15 Float Chamber Gasket 1
Float Chamber Gasket -
1-16 Screw 4
Screw -
1-17 Drain Screw 1
Drain Screw -
1-18 Gasket 1
Gasket -
1-19 Carburetor Cover 1
Carburetor Cover -
1-20 Carburetor Cover Gasket 1
Carburetor Cover Gasket -
1-21 Screw 4
Screw -
1-22 Stop Screw 1
Stop Screw - L=15
1-23A Spring 1 L=14
1-23B Nut -
1-24 Plate -
1-25 Screw -
1-26 Retaining Ring 1
1-27 Cap 1
1-28 Rubber Boot 1
1-29 Plunger Complete 1
Plunger Complete -
1-30 Coil Spring 1
Coil Spring -
1-31 Diaphragm Cover 1
Diaphragm Cover -
1-32 Screw 3
Screw -
1-33 Drain Screw 1
1-34 Drain Screw Gasket 1
1-35 Check Valve 1
Check Valve -
1-36 Fuel Filter 1
2 Choke Link Rod 1 for MF & EF
3 Rod Snap, 3.2-2 1 for MF & EF
4 Choke Rod 1 for MF & EF
5 Bushing 1 for MF & EF
1-37 O-ring 2
1-38 O-ring 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
