3.2.2 Q210 GROUND PLAN
Boltin
g
holes
Product pipe 1 with TQP
or Suction pipes for
PASV3
Side B
Side A
Product pipe 2 with TQP
or Satellite product 2
Electrical supply
Dimensions shown are from base of chassis
Side - Product outlet (product 2) (std)
Vapour recovery (default)
or Satellite connection
product 2
Vapour recovery product 1 (only
if return line per product) or
Satellite connection product 1
325
175
252
112
249
670
635
595
572
432
212
88
35
350
25
