TOMAHAWK TW-9010
6 PIN Remote Start-up Power Socket
1. Blue wire – central contact for central lock opening relay
2. Blue and grey wire – normally open contact for central lock opening relay
3. Blue and black wire – normally closed contact for central lock opening relay
4. Green wire - central contact for central lock closing relay
5. Green and grey wire – normally open contact for central lock closing relay
6. Green and back wire – normally closed contact for central lock closing relay
18 PIN Main Socket
1. Black wire – system “-“
(Ensure reliable contact)
2. Blue wire – wire for cabin light ON or window UP
- 300mA when disarming / arming system (programmable)
3. Black and red wire – IGN 3 output
- 300mA while remote start-up procedure, for arrangement of auxiliary ignition
circuits. This wire may become necessary, if ignition lock of vehicle where the system is
installed has more than two ignition circuits, or for enabling immobilizer by-pass modules.
4. Black and yellow wire – starter lock relay wire.
- 300mA after arming system and/or remote start-up procedure and/or in “Anti-hijack”
mode.
ATTENTION!
Blocking relay should only be used for blocking starter to prevent engine stop while movement.
