Topcon EZ2810 - Technical Specifications

D4008 – EN EZ 2810 Operators Manual 8
0.4.0 Technical Specifications
SIZE 10.25” long x 8.0” high x 4” wide (260mm x 190mm x 105mm)
WEIGHT 4.5 lbs. (2.04 Kg)
HELP MESSAGES
Context sensitive help messages in 10 languages, Long messages are
scrolled
LOAD CELL EXCITATION
8 volts D.C. Nominal, Capable of driving ten 350 Ohms transducers, Short
circuit proof
AUTO TEMPERATURE
COMPENSATION
Of internal circuitry for high accuracy weighing measurements
LOAD CELL SIGNAL Compatible with Load Cells with greater than 0.25 mv/v
CONNECTORS AMP plastic weather resistant circular connector. Gold plated contacts.
POWER REQUIREMENTS 10.5 to 16.0 V.D.C. 160 mA nominal with four 350Ω L.C.
SET UP AND
CALIBRATION
Via front panel or USB (???)
GROSS RANGE 999,999 max. display
LOW BATTERY
WARNING
Enabled at 10.5V nominal
POUND/KILOGRAM Selectable
DISPLAY 6 Digit Chip on Glass LCD 1.7” high
DISPLAY RESOLUTION .01, .02, .05, .1, .2, .5, 1, 2, 5, 10, 20, 50, 100
DISPLAY UPDATE RATE Selectable: 1, 2, 3, 4 times/sec.
MAX. DISPLAY
RESOLUTION
Adjustable to 40,000 counts max.
ZERO TRACKING Selectable, On/Off
SPAN ACCURACY ± (.1% + .005%/ °F) or (.1% + 0.009% °C) full scale ± 1 output count
MOTION DETECTION Selectable, On/Off
ZERO ACCURACY
(.005%/ °F) or (0.009% °C) full scale ±1 output count for 0.5 mv/v
transducer
ENVIRONMENTAL
ENCLOSURE
IP65, IEC 529
WEIGH ALGORITHM
3 internally selectable digital filters to optimize performance (General,
Slow, and Fast)
HOLD MODE
Used in mobile applications to stabilize displayed weight while moving the
scale
NON-VOLATILE
MEMORY
Standard
OPERATING TEMP -29°C to 60°C -20°F to 140°F
2 REMOTE INPUTS
(Power/Remote ports)
Tare / Print / Hold / Net Gross / M+ / Zero / TR Hold / Re-enter Preset /
Switch
REMOTE PORT
Power Output
2 x Large Display LED Remote Displays (RD4000) or 3 x Standard
Display Remote Displays (RD2500V)
