Preparation
9
Installing RC-3R onto
the prism unit A6R
1
Match the receiving windo
w with the front ma
rk and insert the mounting
hooks on the Prism
Unit A6R into the mounting holes of the RC-3R.
2
T
urn the RC-3R towards the front
mark (until you hear a click).
Front mar
k
Mounting hooks
Mounting
holes
10
