Nomenclature and Functions
7
Remote Controller Handle Unit RC-3H
GTS-900A, GPT-9000A series total station requires RC-3H to enable turn-round motions and
optical communications with RC-3H.
GTS-900A, GPT-9000A series carrying case is large enough to house the total station fitted with
RC-3H.
Do not damage or shock connection points. It may cause malfunction.
Detectors
(at five points)
Fixing knob
RC-3H
Connection points
