Topcon RC-3 User Manual

Setting Mode
18
Setting Mode
In this mode, following items can be set.
Setting Items
How to Set
Remote control channel
1
With the power ON, push the channel change key on the panel once.
Current channel will be displayed (Default setting: 1)
2
While the channel is displayed (approx. 5 seconds), push the key once again.
It will switch to the next channel.
3
Repeat step 2 until the channel you wish to set is displayed.
(The optical communication channel setting cannot be changed during turn-round.)
Items Selecting item Description
Optical
communication
channel
1 to 6
Sets a channel to be used for communications. The
same communication channel must be assigned to
both RC-3R and the total station.
Prevents interference of communication when several
systems consisting of a total station and a RC-3 are
used at one site.
Communication
baud rate
9600/4800
Select communication speed.
