Basic Operation
12
Setting for Optical communications with total station
The following settings is prerequisites for the optical communications to take place between the
total station (or an application program) and RC-3R.
• When communicating by using [EXT.LINK] of the application software
(AP-L1 communication mode).
1
Set Parameter for RC.
Operation:
Main menu - Program Modes (Prog) - (EXT.LINK) - (Setting) - (RC)
2
Execute the External Link.
Operation:
Main menu - Program Modes (Prog) - (EXT.LINK) - (Execute)
• When communicating without using [EXT.LINK] (GTS communication
mode).
1
Set the parameters in the Parameters Setting Mode. (Refer to Table of item to be set shown
as follows.)
Operation:
Main menu - Parameters Setting Modes (SETUP) - (communication) - (RC)
2
Execute the Standard Measurement Mode.
Main menu-Standard Measurement Mode (Meas)
Set the parameters in Setting Mode.
Refer to Table of item to be set in Setting Mode.
Connect a data collector to be used to the serial RS-232C connector of the RC-3R, and set the
items as follows.
B.Rate
9600
Data.L
8
Parity
none
Stop Bit
1
Setting Parameters in total station
Setting Parameters in RC-3R
Setting Parameters of Communication port in Data Collector
To Next Page
