Topcon RL-HV Series - CHANGING THE SETTINGS; 8.1 Masking (Laser Beam Shutter) Setting; 8.2 Speed Setting; 8.3 Manual Mode ON;OFF Setting

35
8. CHANGING THE SETTINGS
4. When desired masking is displayed, press the key to finish.
The rotary head speed can be set to 600 or 300 R.P.M.
1. Press key to display the menu screen.
2. Use the key to select the rotary head speed (SPEEd)
and press the key.
3. When the rotary head speed selected using the keys,
press the key to finish.
8.2 Speed setting
