37
8.
CHANGING THE SETTINGS
"6.2
Height
Alert Function"
1.
Press
ke
y
.
2.
Press the
or
key and select Safety Lock ON
/OFF
(Hl.ALr), and press the
key
.
3.
Press the
or
key and select ON or OFF
, and press the
key
. Setting is complete.
T
o shift to other modes, press the
key
.
8.4
Height Alert
ON/OFF
39
41
