70
INDIVIDUAL OPERATIONS
4 Bring the left positioning bar to the left end of iris by pressing the (for
moving left) and (for moving right).
5 Press the .
6 The guide mark moves right.
7 Bring the right positioning bar to the right end of iris by pressing the
(for moving left) and (for moving right).
8 Press the .
9 The cornea diameter is displayed.
10 Press the . The measurement mode of left eye sets in.
Measure also the right eye in like manner.
11 After displaying data for both eyes, press the to return to the
measurement screen.
If it is necessary to move the left positioning bar again, press the
. When the is pressed
further, right and left positioning bars return to the initial positions.
AUTO START SWITCH
TARGET IMAGE SWITCH
CORNEA DIAMETER
RL
L
R L
MEASUREMENT SWITCH
AUTO START SWITCH
TARGET IMAGE SWITCH
MEASUREMENT MODE SWITCH MEASUREMENT MODE SWITCH
MEASUREMENT SWITCH
CORNEA DIAMETER
R 13.00 L
RL
L
MEASUREMENT SWITCH
