Default Settings
3
SRL-35 Operator’s Manual P/N: 1003224-01
Default Settings
The SRL-35 is shipped with the following default settings (unless otherwise specifically agreed):
Table 6. Default Settings
DEFAULT VALUES OF THE ADJUSTABLE SETTINGS (user can change settings later on)
Setting Default value Range
Radio frequency
Operating TX frequency 438.000 MHz Range: 403 - 473 MHz
Operating RX frequency 438.000 MHz Range: 403 - 473 MHz
Reference Frequency 438.000 MHz Range: 403 - 473 MHz
Channel Spacing 12.5 kHz Range: 12.5, 20 or 25 kHz
Radio settings
TX Power 35 W Range: 10, 20, 25 and 35 W
Signal threshold -115 dBm -80 … -118 dBm
FCS OFF ON/OFF
TX-Start Delay 0 ms 0-65535 ms
Radio Compatibility SATEL 3AS SATELLINE-3AS, PCC 4-FSK, PCC GMSK, TrimTalk 450s
(P), TrimTalk450s (T), PCC-FST
Addressing
RX Address OFF ON/OFF
TX Address OFF ON/OFF
RX addressing to RS port OFF ON/OFF
TX address auto switch OFF ON/OFF
Serial port 1
Status ON ON/OFF
Interface RS-232 Fixed
Data speed 9600 bps 300, 600, 1200, 2400, 4800, 9600, 19200, 38400 bps
Data bits 8 7, 8, 9
Parity bits None None, Even, Odd
Stop bits 1 1, 2
Handshaking Handshaking lines apply to the DATA-port.
CTS Clear to send Clear to send, TX buffer state
CD RSSI threshold RSSI- threshold, Data on channel,
Always ON, External Antenna Control
RTS Ignored Ignored, Flow Control, Reception Control
Pause length 3 bytes 3 … 255 bytes
Additional setup
Error correction OFF ON/OFF
