Appendix B
Changing Parameters Using a Terminal Device
66
SRL-35 Operator’s Manual P/N: 1003224-01
Number 3 is pressed in the Main Menu.
The new value is displayed in the menu.
To get back to the main menu press ESC (and then E for Exiting and saving).
The address is given in hexadecimal format with four digits and the number of different addresses is thus
over 65 000.
Changing Serial Port Settings (Port 1)
The settings of serial PORT 1 can be modified by selecting main menu selection ”4”. In the following
example, the data transfer speed of PORT 1 is modified (9600 bit/s
19200 bit/s), followed by the
modification of the number of data bits (8 à 7), then the number of parity bits (NONE
EVEN) and finally
the number of stop bits is changed (1 à 2).
NOTE!
The radio modem has one serial port, PORT 1 which complies with the RS-232 standard. PORT 2 is not in
use and the settings of serial PORT 2 cannot be changed. Number 4 is pressed in the Main menu.
Addressing setup
Toggle ON/OFF values. Current value shown.
------------------------------------------
1) RX address OFF
2) TX address OFF
3) RX address to RS port OFF
4) Change primary RX address
5) Change primary TX address
6) Change secondary RX address
7) Change secondary TX address
8) TX address autoswitch OFF
Enter selection or ESC to previous menu >1
Addressing setup
Toggle ON/OFF values. Current value shown.
------------------------------------------
1) RX address ON 0000/0000
2) TX address OFF
3) RX address to RS port OFF
4) Change primary RX address
5) Change primary TX address
6) Change secondary RX address
7) Change secondary TX address
8) TX address autoswitch OFF
Enter selection or ESC to previous menu >4
RX address setup
----------------
RX address ON 0000/0000
Enter new address (HEX) or ESC to previous menu >0020 Enter
RX address setup
----------------
RX address ON 0020/0000
Enter new address (HEX) or ESC to previous menu >
